Solenoid
Main solenoid and
manual trigger release
lever

Antennas
Internal antenna has a
range up to 75 feet. The
removable, external
antenna has a range up
to 175 feet.

Rear Housing Vent
& Receiver Coding
Button Access
Do not allow moisture to
enter the device through
this area.

Rear Cover
Remove if water
may have intruded,
allow to air dry
in a cool place.

Reward Storage
Holds reward items such
as balls, tugs, food, etc.
less than 2.9" in diameter.

Internal Spring Pack
Manually cocked, the internal spring pack is capable of delivering
reward with enough speed and distance to engage
prey drive in most animals.

Adjustable Bi-Pod Legs
For ease of setup, the legs
can extend, increasing or
decreasing the trajectory
of the reward.

Operation

Turn the power switch on. Compress and latch the spring pack: put the push tube in the barrel and press to the rear; while at the same time, pressing the trigger lever to the rear. Release the lever to latch.

Operation of the Bi-Pod Legs
To extend the legs, unfold the
legs and turn the leg-lock screws counter-clockwise.
Pull on the rubber feet until locked to extend the legs
to full length. Release legs by depressing leg-lock latch.
The legs can be adjusted to an intermediate length by
turning the leg-lock screws clockwise.

Transmitter/Receiver Signal Ranges

(open air level surface)

Warranty

One year warranty on all major components: main trigger solenoid, internal receiver, barrel housing, rear housing, piston spring pack assembly, trigger assembly.

Ninety day warranty on all other parts and hardware. Warranty void on any damaged parts caused by improper use, water damage, heat damage, or stripped screw holes. Owner is responsible for any shipping charges after 90 days. All warranty issues to be authorized and performed by Reiter Systems, LLC. Contact warranty@k-9bsd.com for more information.

Warnings

This device is intended for use by professional animal trainers. Never leave the device where children could have access to it. When the device is activated, the piston will rapidly exit the barrel by one inch.
